Fully Automatic 6-Head Filling and Crimping Machine
It is used for fully automatic 6-head filling and capping of small-volume liquid products, using PLC control and peristaltic pump filling.
- Final configuration confirmed before quotation
- Customization and accessories reviewed by application
- Export packing and documentation available on request
- Cosmetics, medical aesthetics, food, health products and pharmaceuticals
Key product features
-
Japan Panasonic PLC control system
-
Detected using Panasonic photoelectric sensor
-
Filling uses high-precision peristaltic pump
-
The over-buffering turntable is equipped with an anti-bottle tipping device
-
In and out of the bottle astrolabe positioning
-
Using vibrating plate to automatically remove plugs
-
Frequency conversion speed regulation, independent speed regulation control
-
The whole machine is mainly made of high-quality SUS304 stainless steel
Technical specifications
Specifications are organized by system so different equipment types can present the parameters that matter for their application.
Technical specifications
| Production capacity | 180-200 bottles/minute |
|---|---|
| Number of filling heads | 6 heads |
| Filling accuracy | ≤±3% |
| Filling range | 2ml-30ml |
| Power supply | 220V/50Hz |
| Air source | 0.6-0.8MPa |
| Net weight | 600kg |
| Dimensions | 1900×1300×1500mm |
Specifications may change with configuration and customization. Final data is subject to the confirmed quotation.
Fully Automatic 6-Head Filling and Crimping Machine
Product overview
It is used for fully automatic 6-head filling and capping of small-volume liquid products, using PLC control and peristaltic pump filling.
Product features
- Japan Panasonic PLC control system
- Detected using Panasonic photoelectric sensor
- Filling uses high-precision peristaltic pump
- The over-buffering turntable is equipped with an anti-bottle tipping device
- In and out of the bottle astrolabe positioning
- Using vibrating plate to automatically remove plugs
- Frequency conversion speed regulation, independent speed regulation control
- The whole machine is mainly made of high-quality SUS304 stainless steel
Scope of application
- Cosmetics
- Medical beauty
- food
- health care products
- Medicines
Technical parameters
| Device model | MX-GZJSZG |
|---|---|
| production capacity | 180-200 bottles/minute |
| Number of filling heads | 6 heads |
| Filling accuracy | ≤±3% |
| Filling range | 2ml-30ml |
| power supply | 220V/50Hz |
| Air source | 0.6-0.8MPa |
| Net weight | 600kg |
| Dimensions | 1900×1300×1500mm |
For international buyers, quotation confirmation can include configuration, accessories, packing method, export documents, inspection photos or videos and shipping terms.
